WC67Y Series Simple CNC Press Brake
Specializing in the production of "Teng" brand series of hydraulic shearing machine, mechanical shearing machine, hydraulic bending machine
Key words:
WC67Y Series Simple CNC Press Brake
Product Details
Product Features:
The whole machine is made of steel plate welded structure, using vibration aging to eliminate internal stress, the machine has high strength and good rigidity; hydraulic double oil cylinder up and down transmission, mechanical block, torsion shaft synchronization, stable and reliable operation, high precision; the rear baffle and the upper slider are equipped with encoders, and the digital display system makes the rear baffle material and the upper slider position display more accurate, thus further improving the working precision of the machine.
The distance of the rear baffle material and the stroke of the slider are adjusted by a simple numerical control LCD display and manual fine adjustment, and it is equipped with an LCD display device, which is convenient and quick to use;
Product Parameters:
Specification Model | Nominal Pressure | Worktable Length | Distance Between Columns | Throat Depth | Slider Stroke | Maximum Opening Height | Main Motor Power |
kn |
mm |
mm |
mm |
mm |
mm |
kw |
|
WC67Y-63/2500 | 630 | 2500 | 2000 | 250 | 100 | 370 | 5.5 |
WC67Y-63/3200 | 630 | 3200 | 2500 | 250 | 100 | 370 | 5.5 |
WC67Y-80/3200 | 800 | 3200 | 2500 | 250 | 120 | 380 | 5.5 |
WC67Y-100/3200 | 1000 | 3200 | 2500 | 320 | 120 | 400 | 5.5 |
WC67Y-100/4000 | 1000 | 4000 | 3000 | 320 | 120 | 400 | 7.5 |
WC67Y-125/3200 | 1250 | 3200 | 2500 | 320 | 120 | 400 | 7.5 |
WC67Y-125/4000 | 1250 | 4000 | 3000 | 320 | 120 | 400 | 7.5 |
WC67Y-160/3200 | 1600 | 3200 | 2500 | 320 | 180 | 450 | 7.5 |
WC67Y-160/4000 | 1600 | 4000 | 3000 | 320 | 180 | 450 | 11 |
WC67Y-160/6000 | 1600 | 6000 | 4100 | 320 | 180 | 450 | 11 |
WC67Y-200/3200 | 2000 | 3200 | 2450 | 320 | 200 | 470 | 11 |
WC67Y-200/4000 | 2000 | 4000 | 3000 | 320 | 200 | 470 | 15 |
WC67Y-200/6000 | 2000 | 6000 | 4500 | 320 | 200 | 470 | 15 |
WC67Y-250/3200 | 2500 | 3200 | 2450 | 400 | 250 | 540 | 15 |
WC67Y-250/4000 | 2500 | 4000 | 3000 | 400 | 250 | 540 | 15 |
WC67Y-250/6000 | 2500 | 6000 | 4600 | 400 | 250 | 540 | 15 |
WC67Y-300/4000 | 3000 | 4000 | 3000 | 400 | 250 | 560 | 18.5 |
WC67Y-400/4000 | 4000 | 4000 | 3100 | 400 | 250 | 560 | 18.5 |
WC67Y-400/6000 | 4000 | 6000 | 4500 | 400 | 250 | 560 | 22 |
WC67Y-500/4000 | 5000 | 4000 | 3100 | 500 | 250 | 600 | 30 |
WC67Y-500/6000 | 5000 | 6000 | 4500 | 500 | 250 | 600 | 30 |
WC67Y-600/8000 | 6000 | 8000 | 4500 | 500 | 300 | 650 | 45 |
WC67Y-800/6000 | 8000 | 6000 | 4500 | 500 | 300 | 650 | 55 |
WC67Y-1200/6000 | 12000 | 6000 | 4500 | 500 | 300 | 650 | 75 |
Due to the continuous improvement of products, if there are inconsistencies between the sample technical data and the actual product data, the technical parameter agreement between both parties shall be followed, and no further notice will be given! |
Purchase our machine tools, you can enjoy 1 year warranty, lifetime maintenance. In the Jiangsu, Zhejiang and Shanghai areas, we will arrive at the scene within 24 hours of receiving the customer's Tel, and 48 hours in remote areas. Customer satisfaction is our service tenet! Welcome to Tel.
